Road Case Liners & Enclosures
Structured Support for Rack-Mounted Systems
Built for the Work That Demands Reliability
Motion Laboratories Road Case Liners and Enclosures provide the internal structure needed to securely mount and protect rack-mounted equipment inside ATA road cases. Designed to integrate directly with Motion Laboratories road case systems, these liners add strength, organization, and mounting precision to mobile and installed setups.
Available in steel and aluminum configurations, these liners are designed to support a wide range of rack heights and depths, giving production teams the flexibility to build reliable, purpose-driven rack systems.
Built for Secure Equipment Integration
Road case liners provide a stable internal framework for mounting power distribution equipment, control systems, and rack-mounted devices. They are available in multiple depths and rack heights to accommodate different system requirements and case sizes.
Key Features
- Steel or aluminum construction for structural strength
- Rack rail mounting for standardized equipment installation
- Options for single-lid and double-lid case compatibility
- Available in multiple depths and rack heights
- Options with clamp mounts, flyrings, and specialty cutouts
- Powder-coated and corrosion-resistant finishes available
Flexible Configurations for Professional Applications
Motion Laboratories offers a wide range of liner configurations to support different workflows and equipment layouts, including:
- Steel liners for 1-lid and 2-lid road cases
- Deep and shallow depth options
- Versions with integrated clamp mounts and flyrings
- Rear-access compatible designs
- Specialty aluminum enclosures for specific applications
These options help ensure equipment is mounted securely and protected during transport and use.
Designed for Production Environments
Whether supporting power distribution, control systems, or custom rack builds, Motion Laboratories Road Case Liners and Enclosures provide a solid foundation for professional equipment. Built for consistent performance and compatibility with Motion Laboratories road cases, these liners help ensure reliable system integration in demanding production environments.
| Part # | Description |
|---|---|
| B-12-002-0001 | 1Lid Case Steel Liner, 5Space, 7.75″ Deep |
| B-12-002-0002 | 1Lid Case Steel Liner, 6Space, 7.75″ Deep |
| B-12-002-0003 | 1Lid Case Steel Liner, 7Space, 7.75″ Deep |
| B-12-002-0004 | 1Lid Case Steel Liner, 8Space, 7.75″ Deep |
| B-12-002-0005 | 1Lid Case Steel Liner, 9Space, 7.75″ Deep |
| B-12-002-0006 | 1Lid Case Steel Liner, 10Space, 7.75″ Deep |
| B-12-002-0007 | 1Lid Case Steel Liner, 11Space, 7.75″ Deep |
| B-12-002-0008 | 1Lid Case Steel Liner, 12Space, 7.75″ Deep |
| B-12-002-0009 | 1Lid Case Steel Liner, 13Space, 7.75″ Deep |
| B-12-002-0010 | 1Lid Case Steel Liner, 14Space, 7.75″ Deep |
| B-12-002-0011 | 1Lid Case Steel Liner, 15Space, 7.75″ Deep |
| B-12-002-0012 | 1Lid Case Steel Liner, 16Space, 7.75″ Deep |
| B-12-002-0013 | 1Lid Case Steel Liner, 17Space, 7.75″ Deep |
| B-12-002-0014 | 1Lid Case Steel Liner, 18Space, 7.75″ Deep |
| B-12-002-0015 | 1Lid Case Steel Liner, 19Space, 7.75″ Deep |
| B-12-002-0016 | 1Lid Case Steel Liner, 20Space, 7.75″ Deep |
| B-12-002-0017 | 1Lid Case Steel Liner, 21Space, 7.75″ Deep |
| B-12-002-0018 | 1Lid Case Steel Liner, 22Space, 7.75″ Deep |
| B-12-002-0019 | 1Lid Case Steel Liner, 23Space, 7.75″ Deep |
| B-12-002-0020 | 1Lid Case Steel Liner, 24Space, 7.75″ Deep |
| B-12-002-0024 | 1Lid Case Steel Liner, 28Space, 7.75″ Deep |
| B-12-002-0028 | 1Lid Case Steel Liner, 8Space, 7.75″ Deep, 2Clamp Mounts, 1Flyring, For Rear Access Case |
| B-12-002-0029 | 1Lid Case Steel Liner, 8Space, 7.75″ Deep, Thru Hole for 2Clamps, 1Flyring |
| B-12-002-0030 | 1Lid Case Steel Liner, 11Space, 7.75″ Deep, 2Clamp Mounts, 1Flyring, For Rear Access Case |
| B-12-002-0031 | 1Lid Case Steel Liner, 13Space, 7.75″ Deep, 2Clamp Mounts, 1Flyring, For Rear Access Case |
| B-12-002-0032 | 1Lid Case Steel Liner, 12Space, 7.75″ Deep, 2Clamp Mounts, 1Flyring, For Rear Access Case |
| B-12-002-0033 | 1Lid Case Steel Liner, 8Space, 7.75″ Deep, Thru Hole for 2Clamps, 1Flyring on rear and Thru Holes for 2Clamps on top |
| B-12-002-0035 | 1Lid Case Steel Liner, 8Space, 7.75″ Deep, 1/2″ Thru Hole for 2Clamps, 1Flyring |
| B-12-002-0037 | 1Lid Case Steel Liner, 8Space, 7.75″ Deep, W/2 Black Clamp Mounts and 1Flyring, Black, For Rear Access Case |
| B-12-002-0038 | 1Lid Case Steel Liner, 10Space, 7.75″ Deep, 2Clamp Mounts, 1Flyring, For Rear Access Case |
| B-12-002-0039 | 1Lid Case Steel Liner, 11Space, 7.75″ Deep, 3Clamp Mounts |
| B-12-002-0040 | 1Lid Case Steel Liner, 15Space, 7.75″ Deep, Thru Hole for 2Clamps, 2Flyring |
| B-12-003-0001 | 2Lid Case Steel Liner, 6Space, 31″D |
| B-12-003-0002 | 2Lid Case Steel Liner, 7Space, 31″D |
| B-12-003-0003 | 2Lid Case Steel Liner, 8Space, 31″D |
| B-12-003-0004 | 2Lid Case Steel Liner, 9Space, 31″D |
| B-12-003-0005 | 2Lid Case Steel Liner, 10Space, 31″D |
| B-12-003-0006 | 2Lid Case Steel Liner, 11Space, 31″D |
| B-12-003-0007 | 2Lid Case Steel Liner, 12Space, 31″D |
| B-12-003-0008 | 2Lid Case Steel Liner, 13Space, 31″D |
| B-12-003-0009 | 2Lid Case Steel Liner, 14Space, 31″D |
| B-12-003-0010 | 2Lid Case Steel Liner, 15Space, 31″D |
| B-12-003-0011 | 2Lid Case Steel Liner, 16Space, 31″D |
| B-12-003-0012 | 2Lid Case Steel Liner, 17Space, 31″D |
| B-12-003-0013 | 2Lid Case Steel Liner, 18Space, 31″D |
| B-12-003-0014 | 2Lid Case Steel Liner, 19Space, 31″D |
| B-12-003-0015 | 2Lid Case Steel Liner, 20Space, 31″D |
| B-12-003-0016 | 2Lid Case Steel Liner, 21Space, 31″D |
| B-12-003-0017 | 2Lid Case Steel Liner, 22Space, 31″D |
| B-12-003-0018 | 2Lid Case Steel Liner, 23Space, 31″D |
| B-12-003-0019 | 2Lid Case Steel Liner, 24Space, 31″D |
| B-12-003-0020 | 2Lid Case Steel Liner, 25Space, 31″D |
| B-12-003-0021 | 2Lid Case Steel Liner, 26Space, 31″D |
| B-12-003-0022 | 2Lid Case Steel Liner, 27Space, 31″D |
| B-12-003-0023 | 2Lid Case Steel Liner, 28Space, 31″D |
| B-12-003-0024 | 2Lid Case Steel Liner, 29Space, 31″D |
| B-12-003-0025 | 2Lid Case Steel Liner, 30Space, 31″D |
| B-12-003-0100 | 2Lid Case Steel Liner, 6Space, 23.5″D |
| B-12-003-0101 | 2Lid Case Steel Liner, 7Space, STD, 23.5″D |
| B-12-003-0102 | 2Lid Case Steel Liner, 8Space, STD, 23.5″D |
| B-12-003-0106 | 2Lid Case Steel Liner, 12Space, 23.5″D |
| B-12-003-0108 | 2Lid Case Steel Liner, 14Space, STD, 23.5″D |
| B-12-003-0109 | 2Lid Case Steel Liner, 15Space, 23.5″D |
| B-12-003-0111 | 2Lid Case Steel Liner, 17Space, 23.5″D |
| B-12-003-0114 | 2Lid Case Steel Liner, 20Space, STD, 23.5″D |
| B-12-003-0204 | 2Lid Case Steel Liner, 9Space, 36″D |
| B-12-004-0004 | Enclosure, 8Space, 1Lid, Rack Rail, Steel, Black |
| B-12-004-0054 | Enclosure Assembly, 8Space 1Lid, Rack Rail, Clamps, Steel, Black |
| B-12-004-0057 | Enclosure Assembly, 11Space 1Lid, Rack Rail, Clamps, Steel, Black |
| B-12-005-1000 | 1Lid Case Aluminum Enclosure, 12Space, 9.75″ Deep, Custom, Black Powder coat, Housing Class-7 |
| B-12-005-1001 | 1Lid Case Aluminum Enclosure, 12Space, 9.75″ Deep, Custom, Black Powder coat, Housing Class-7, No Handles |
| B-12-005-1002 | 1Lid Case Aluminum Enclosure, 12Space, 9.75″ Deep, Custom, Black Powder coat, Housing Class-7, 2Clamp Mounts, 1Flyring |
| B-12-005-1003 | 1Lid Case Aluminum Enclosure, 11Space, 9.75″ Deep, Custom, Black Powder coat, Housing Class-7 |
